20x40 ft Container Shelter with Closed Back Panel
The 20x40 ft Container Shelter with Closed Back Panel boasts versatile tarpaulins in various materials and a robust PE back panel. This spacious, durable shelter provides excellent protection, making it ideal for diverse applications in any environment.
How to Install the Container Shelter?
Specification
| Description | Specifications |
| Model | C2040 Dome Container Shelter |
| Dimension (ft) | W20xL40xH6.6 |
| Frame | Single Truss Galvanized Tube |
| Steel Structure | High-Grade Hot Dip Galvanized Steel |
| Fabric |
|
| Fabric Feature | Waterproof, UV-resistant, Fire-Retardant, Self-Cleaning Property |
| Temperature resistance | -22 - +158 °F |
| Front/back walls (optional) |
|
| Arch Interval | 5 ft |
| Arch Ă (mm) | Ă45x1.5 |
| Purlin Ă (mm) | Ă32x1.2 |
| Tension System | Pipe and Ratchet Tie-Down System |
| Easy Installation | Twist lock and clamp installation |
| Weld | No welding required |
| Snow Load | 48 lbs/ft² |
| Wind Load | 50 miles/h |
| Average assembly time for DIY with 4 persons | Max. 1 day |
| Safety | The tarpaulin is PFAS-free and EU REACH compliant. |
| Tarp Lifespan | 7-10 years, depending on the type of fabric and environmental conditions. |
| Frame Lifespan | 15+ years |
| Warranty |
|
Note
- The term âlifespanâ refers to the durability of the materials themselves, not to the installation of the canopy structure.
- The assembled canopy's structural integrity may be impacted by sudden weather changes (e.g., high winds, heavy snow, rain). Always check the forecast and consider the described limitations.
Feature
- Style: Pony Wall.
- The tarpaulin is PFAS-free and EU REACH compliant.
- CSA/TUV Snow Rating Report.
- SGS fabric Certificate.
- No pole inside, and 100% of the interior space is available.
- Usage: Warehouse, farm tent, equipment storage, car lot, temporary office, livestock house, workshop, parties, big event.
Package Size
Box A:
- LxWxH (inch): 75x30x20
- Weight (lb):Â 805
- A forklift or equivalent is required for unloading
Box B:
- LxWxH(inch): 76x28.5x6
- Weight(lb): 86
A forklift or equivalent is required for unloading.
Parts
- Cover replacement
- Front Panel
- Rear Panel
- Half Panel
Select Material
From $2,690.00
20x40 ft Container Shelter with Closed Back Panelâ
$2,690.00
